FR-MINI Dough Sheeter - Freeway Machine

Dough Sheeter/

FR-MINI Dough Sheeter

Technical Specifications

Electrical: 220 V / 50 ou 60 Hz / 3 Phase

Power: 1.2 kW

Working position dimensions (DWH): 2557 x 996 x 1363 mm

Machine weight: 280kg

Machine body material: Stainless steel

Conveyor belt width: 500 mm

Conveyor belt length: 2000 mm

Conveyor belt material: PVC

Roller Diameter: 85 mm

Automatic flour duster: YES

Maximum product/recipe no.: 30 records

Dought sheet thickness range: 0.8 ~ 45 mm

Maximum dough weight: 5kg



  • Détails du produit
  • Product Features

FR-MINI Dough Sheeter

FR-MINI Dough Sheeter installed with micro-embedded computer and LCD touch panel which provides user-friendly interaction tools that makes it easy to be operated.

It allows users to create rolling programmes for their specific products, save their customized parameters, such as dough thickness, dough width, roller gap adjustment, belt speed, flour duster on/off.

Once the user selects a specific product program and press start button, the machine will automatically work in accordance with pre-setting parameters.

There are highly-sensitive sensors which can detect the physical change of the dough sheet size with error range in millimeter.

When the desired width has been reached, the machine will automatically shut itself off. Then, the user can proceed with next work.

Applying this machinery means great leap forward of efficiency and accuracy in mass production.

    • Made of high quality stainless steel; ideal use for long period of time
    • User can create rolling programmes for specific products and save them
    • Automatic roller gap adjustments
    • Suitable for small-and-medium size bakeries, restaurants, and hotels
    • Equipped with preset roller thickness control
    • Foldable tables for space-saving storage and retractable end tables
    • Safety features: safety guards, emergency stop switch, thermal overload device
  • Bracket board, the base, the safety guard and the tray bar are stainless steel material
